20" SN .325" 1,5 mm S35G

SKU: 967 69 08‑20

20" SN .325" 1,3 mm SP33G

SKU: 967 69 08‑50

Chain speed at max power

64.3 fts

Cylinder displacement

3.06 cu.inch

Power output

4 hp

Torque, max.

3.15 Nm

Torque, max. at rpm

7,800 rpm

Clutch engagement speed (±120)

3,900 rpm

Electrode gap

0.02 in

Idling speed

2,800 rpm

Ignition module air gap

0.01 in

Maximum power speed

10,200 rpm

Oil pump type

Adjustable flow, no flow at idle

Spark Plug

NGK CMR6H

Equipment

Recommended bar length, min

13 in

Pitch

.325"

Recommended bar length, max

20 in

Chain type

S35G

Bar length

50 cm

Bar length (inch)

20 in

Sprocket type

Rim 7

Dimensions

Weight (excl. cutting equipment)

11.7 lbs

Sound and noise

Sound pressure level at operators ear

107 dB(A)

Sound power level, guaranteed (LWA)

117 dB(A)

Sound power level, measured

115 dB(A)

Vibration

Equivalent vibration level (ahv, eq) rear handle

4.9 m/s²

Equivalent vibration level (ahv, eq) front handle

4 m/s²

Lubricant

Oil tank volume

0.68 US pint

Lubricant type (Engine)

Husqvarna 2 stroke or equiv. at 50:1

Emission

Exhaust emissions (CO2 EU V)

813 g/kWh
